CFW BAUM7X7 200x230x15x14 FKM 585 Oil Seal High Temp Rubber Part for Heavy Industrial Machinery Maintenance Bulk Wholesale In Stock
Product Details
| Part NO | 0000407051 | Type | BAUM7X7 |
|---|---|---|---|
| Size | 200x230x15x14 | Material | FKM 585 |
| Hardness | 75 Shore A | Using Temperature | FKM :-30°C To +200°C |
| Related Products | BAU3X2,B1FG ,B2U3,BAFG,B1FUD2SL,BAUM3SLX7,B2FUD BAUMX7,BAU3SL. | Properties | Future Resistant To Heat, Oil, Fatigue, Aging And Friction |
| Appliion Machine | Ship, Excavator, Pump Hydraulic Machine Rotary Shaft, Rotary Drilling Rig, Hydraulic Loader | Appliion Range | Main Pump Of Excavator Or Other Construction Machines |
| Way By Arrival | Shipping By Sea,air Express,DHL ,EMS, FADEX,TNT. | ||
| Highlight | FKM rubber oil seal,high temp oil seal for machinery,heavy industrial oil seal |
||
Product Description
CFW Rubber Oil Seal BAUM7X7 200x230x15x14 75 FKM 585
1 . Detailed Product Description
| Specification / Feature | Details |
| Product Name | Premium Rotary Shaft Oil Seal / Radial Shaft Seal |
| OEM Part Number | 0000407051 |
| Model / Design | BAUM7X7 (Double Lip with Dust Guard) |
| Exact Size | 200mm (Inner Dia) × 230mm (Outer Dia) × 15mm/14mm (Width) |
| Materia | FKM 585 (Fluorocarbon) |
| Hardness | 75 Shore A |
| Working Temperature | -30°C to +200°C (Extremely resistant to high heat) |
| Working Medium | Mineral oils, synthetic lubricants, hydraulic fluids, fuels, and chemicals |
| Chemical Resistance | Superior resistance to oils, greases, ozone, weathering, and aggressive chemicals |
| Wear & Speed Resistance | Low friction coefficient, optimized for high peripheral speeds and heavy industrial duty |
| Application Industry | Heavy industrial machinery, gearboxes, pumps, and high-temperature rotating equipment maintenance |
2 Applicantions:
3. Product characteristics
- Mechanical Motor pump
- Hydraulic pump
- Construction machinery
- excavator machinery
- mining machinery
- port machinery
- Hoisting Machinery
- Power transmission
- Oil refineries
- Off-highway
- Manufacturing
- Automotive
3. Product characteristics
1. Speed = >Mechanical movement speed is high, the lubriion oil film may be destroyed, because of not good lubriion and friction heating oil seal, cause life is greatly reduced, we use polyurethane or rubber oil seal at 0.03 m/s ~ 0.8 m/s speed within the scope of work is good
2. The temperature= > Low temperature will lower the elasticity of polyurethane or rubber seal, cause leaks, and even the entire oil seal becomes hard and brittle. High temperature can make oil seal volume expansion, soft, cause movement oil seal friction resistance increase rapidly and reduce the compression capacity. Suggest polyurethane or rubber oil seal work continuously - 10 ℃ ~ + 80 ℃ temperature range.
3. Should= > Consider when pressure = "high pressure oil seal compression deformation, repellent extrusion ring, groove processing aspect also have special requirements. For get together ammoniac fat sealing the best working pressure in the range of 2.5 ~ 31.5 MPa.
4. Load=>Oil cylinder can bear larger load, seal and bearing ring in a completely different role, suggest polyurethane sealing ring to ensure that the cylinder can bear larger load
4. Packaging & DeliveryPackaging Details : The original factory packaging
Dellvery Time :
| Quantity(Pieces) | in stock | if goods out of stock Urgent shipment air freight | if goods out of stock, the new order |
| Dellvery Time(days) | 1-2 day | 7-15 days | To be negotiated |
Payment Term Way by delivery:
- Way by delivery: We can arrange the shipping by Sea,air express,DHL ,EMS, FADEX,TNT.
- Payment Term : Western Union, Cash, Bank, PayPal.HSBC,CITY BANK.
5. Picture viewing
6. FAQ
Q1: The pictures you saw here may not be related to the real products. Please contact us for more details if you want to check products.
A. In order to give you fast and accurate pricing information, we need some details about the machine
Q2: Why choose our products:
1. We can provide you a wide range of oil seals.
2. Assessed 25 year gold supplier.
3. Our oil seals has best quality and best service with competitive price.
Q3:To which places have you exported?
A: North America, Europe, Middle East, Africa, Southeast Asia and so on.
Q4: How long is your delivery time?
A: Generally it takes 1-2 days if we have stock.
Q5: How to guarantee your after sales service?
Strict inspection during production
Recheck the products before shipment to ensure our packaging in good condition
Track and receive feedback from our customer
Q6: Could you supply solutions to us?
A: Sure we can.
Q7: Do you have a minimum order requirement?
A: Small trial order is acceptable.
If you are looking for a company to help you building your own brand of seals , seal kits , o-ring kits , or any other OEM services for other products . You have found the right one . Our company provides professional OEM services on seals seal kits , o-ring kits and other products . For details ,
please contact us . We will reply you as soon as possible .
