DINGZING DZ UN Piston Seal TPU/8L953 Blue Polyurethane Hydraulic Rod Seals Hydraulic Cylinder Seals
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | TPU/8L953 | Specific Gravity (ASTM D792) | 1.19 |
---|---|---|---|
Hardness (ASTM D2240) | 93 | Tensile Strength (ASTM D412) | 276 |
100% Modulus (ASTM D412) | 100 | 300%6 Modulus (ASTM D412) | 191 |
Compression Set 70h/70°C (ASTM D395B) | 42 | Compression Set 70h/100°C(ASTM D395B) | 56 |
Max. Working Pressure | 30 Mpa | Working Speed | 0.03~0.5 M/sec |
Working Temperature | -20°C~100°C | Paymeng Terms | T/T, Western Union,Cash ,Paypal |
DINGZING DZ UN Piston Seal TPU/8L953 Polyurethane Hydraulic Rod Seals
1.... Product Details
Mechanical Properties
Material: TPu/8L953
Specific Gravity (ASTM D792): 1.19
Hardness (ASTM D2240): 93
Tensile Strength (ASTM D412): 276
100% Modulus (ASTM D412): 100
300% Modulus (ASTM D412): 191
Compression Set 70h/70°C(ASTM D395B): 42
Compression Set 70h/100°C(ASTM D395B): 56
Working Conditions
Max. Working Pressure: 30 Mpa
Working Speed: 0.03 ~0.5 m/sec
Working Temperature: -20°C~100°C
2.... Company Profile
NFK SEALS :Companies line was established in 1998 which is engaged in the world famous brand of high quality imported seal and oil seal products, product sales, brand agent, technical support and after-sales service into a professional company. Company focused on construction machinery industry market in more than a decade, we have a strong product database, at the same time with business colleagues around the world, has established the good cooperation relations, realizes the resource sharing and complementary advantages, and strive to achieve customer and our win-win situation. The company has established a good market position and a strong customer base with the recognition and complete development of many customers with affordable price, complete products, quick delivery, high quality products and services. We are in line with the tenet of "the best of the company, the first", to serve the customers, and win the confidence of the reputation of the industry and the satisfaction of the customers. |
. Professional team more than 20 years,Professional service and perfect packaging make the seal kit high quality looking and enhance your profit |
3.... Precautions For Product Installation
1. Speed = >hammer mechanical movement speed is high, the lubriion oil film may be destroyed, because of not good lubriion and friction heating oil seal, cause life is greatly reduced, we use polyurethane or rubber oil seal at 0.03 m/s ~ 0.8 m/s speed within the scope of work is good 2. The temperature= > low temperature will lower the elasticity of polyurethane or rubber seal, cause leaks, and even the entire oil seal becomes hard and brittle. High temperature can make oil seal volume expansion, soft, cause movement oil seal friction resistance increase rapidly and reduce the compression capacity. Suggest polyurethane or rubber oil seal work continuously - 10 ℃ ~ + 80 ℃ temperature range. 3. Should= > consider when pressure = "high pressure oil seal compression deformation, repellent extrusion ring, groove processing aspect also have special requirements. For get together ammoniac fat sealing the best working pressure in the range of 2.5 ~ 31.5 MPa. 4. Load=>Oil cylinder can bear larger load, seal and bearing ring in a completely different role, suggest polyurethane sealing ring to ensure that the cylinder can bear larger load |
4.... Related Product Recommendation
NFK HIGH-QUALITY SEALS MANUFACTURING EXPERTS:
Oil Seal -- TC TB TCV TCN DB DC DCY TC4Y ISPID BABSL
Piston seal : SPGW SPGO SPG SPGA NCF ODI OSI OUIS OHM OKH DAS , OK SELA OUY D-8
Rod Seal : IDI IUH ISI IUIS D-2 D-3 D-6
U Seal : UPI UPH USH USI V99F V96H UN
Buff Seal : HBTS HBY HBTTS D-14
Wiper Seal : DKB DKBI DKBI3 DKBZ DKI , DWI DKH DWIR DSI LBI LBH VAY DH ME-2 ME-8
Wearing Ring : WR KZT RYT
Rotary Seal : ROI D-14 SPN
Back Up Ring : N4W BRT-PTFE BRT-NYLON BRT2 BRT3 BRT-G BRT-P BRN2 BRN3
O Ring : Oring Kit P series G series AS series S series M 1.5 series M 2.0 series M 1.9series M 2.4 series
M 3.0 series M4.0 series
Valve Pusher Floating oil seal Bushing hydraulic cylinder seals cylinder seal kits
5.... FAQ
Q2: Why choose our products:
1. We can provide you a wide range of oil seals.
2. Alibaba Assessed 8 year gold supplier.
3. Our oil seals has best quality and best service with competitive price.
Q4: How long is your delivery time?
A: Generally it takes 1-2 days if we have stock.
Q5:The pictures you saw here may not be related to the real products. Please contact us for more details if you want to check products.
A. In order to give you fast and accurate pricing information, we need some details about the machine engine/appliion and the part number of the part you want. And, size and pictures will be better if you are not sure about it. We can check and help you with it.
B. If you can not find the parts you want here, please contact us for an inquiry. Thank you!
Q6:How to contact us?
A:Can you call with us to discuss your questions when you have time? Please call :
+86 13802959131 whatsapp(wechat )Miss Deng
+86 13924029131 whatsapp(wechat )Miss Fion
