Germany Oil Seal CFW Merkel Frudenbery Simrit 25*40*7 Hydraulic Pump Oil Seal

Germany Oil Seal CFW Merkel Frudenbery Simrit 25*40*7 Hydraulic Pump Oil Seal

1 ....German SIMRIT CFW

1. Features: Elastomer seal outer edge, short, soft, and flexible sealing lip with dust lip.
2. Material: Nitrile rubber, code 72NBR902.
3. Color: Blue
Application Conditions:
1. Media: Mineral oils, synthetic oils
2. Temperature (°C): -40°C to 100°C
3. Advantages: Suitable for use in hydraulic components with pressurized working media. The seal between the seal outer edge and the seat bore is reliable, even with high surface roughness, thermal expansion, or split cavities. It offers advantages when sealing low-viscosity and gaseous media. A dust lip is included to prevent general and moderate dust contamination and external intrusion (BAUM4SLX7 model).
4. For synthetic oils (polyalkylene glycols/polyolefins), the maximum operating temperature must not exceed 80°C (if using only NBR).

2 ....Product characteristics

​1. Speed = >Mechanical movement speed is high, the lubriion oil film may be destroyed, because of not good lubriion and friction heating oil seal, cause life is greatly reduced, we use polyurethane or rubber oil seal at 0.03 m/s ~ 0.8 m/s speed within the scope of work is good

2. The temperature= > Low temperature will lower the elasticity of polyurethane or rubber seal, cause leaks, and even the entire oil seal becomes hard and brittle. High temperature can make oil seal volume expansion, soft, cause movement oil seal friction resistance increase rapidly and reduce the compression capacity. Suggest polyurethane or rubber oil seal work continuously - 10 ℃ ~ + 80 ℃ temperature range.

3. Should= > Consider when pressure = "high pressure oil seal compression deformation, repellent extrusion ring, groove processing aspect also have special requirements. For get together ammoniac fat sealing the best working pressure in the range of 2.5 ~ 31.5 MPa.

4. Load=>Oil cylinder can bear larger load, seal and bearing ring in a completely different role, suggest polyurethane sealing ring to ensure that the cylinder can bear larger load



Appliion Range : Main pump of excavator or other construction Machines


3 ....Our advantage





 4 ....Packaging & Delivery



Packaging Details : The original factory packaging

Dellvery Time :



Quantity(Pieces)	in stock	if goods out of stock Urgent shipment air freight	if goods out of stock, the new order
Dellvery Time(days)	1-2 day	7-15 days	To be negotiated



Payment Term Way by delivery:

•
•



• Way by delivery: We can arrange the shipping by Sea,air express,DHL ,EMS, FADEX,TNT.
• Payment Term : Western Union, Cash, Bank, PayPal.HSBC,CITY BANK.

5 ....Oil seal type:

BABSL,BAU3X2,B1FG ,B2U3,BAFG,B1FUD2SL,BAUM3SLX7,B2FUD BAUMX7,BAU3SL.

TC, TB, SC, SB, TB5SY, VC, VB,VK ,TA, SA ,SAY,SCNY2,SCOT,SCOTPLUS

TCV, TCN, TCN-6, TZ TCHD, TCHD-1 ,ISPID, 15Z, 15Z-3,

TC4, TB4, DC, DB,DCY, HSCL,HTC ,HTC9L,HTGL,KC, VR, MG, C N B, SCJY, SCY, VK



Brand	Part number	Type	Material	Color	d	D	t
CFW	2953	BABSL	NBR	Blue	15.0	35.0	6.00
CFW	346627	BABSL	FPM	Blue	15.0	35.0	6.00
CFW	462890	BABSL	NBR	Blue	16.0	26.0	7.00
CFW	423803	BABSL	FPM	Blue	16.0	40.0	10.0
CFW	432519	BABSL	NBR	Blue	17.0	30.0	6.00
CFW	432520	BABSL	FPM	Blue	17.0	30.0	6.00
CFW	12011728	BABSL	NBR	Blue	17.0	35.0	7.00
CFW	37500	BABSL	NBR	Blue	18.0	30.0	6.00
CFW	478785	BABSL	NBR	Blue	18.0	30.0	6.00
CFW	12011517	BABSL	NBR	Blue	18.0	30.0	7.00
CFW	12001667	BABSL	NBR	Blue	18.0	32.0	6.00
CFW	2957	BABSL	NBR	Blue	18.0	35.0	6.00
CFW	418533	BABSL	NBR	Blue	18.0	35.0	6.00
CFW	466758	BABSL	FPM	Blue	19.0	35.0	6.00
CFW	311089	BABSL	NBR	Blue	19.05	31.75	6.35
CFW	463450	BABSL	NBR	Blue	20.0	30.0	7.00
CFW	520073	BABSL	FPM	Blue	20.0	32.0	6.00
CFW	392566	BABSL	NBR	Blue	20.0	32.0	7.00
CFW	2959	BABSL	NBR	Blue	20.0	35.0	6.01
CFW	360092	BABSL	FPM	Blue	20.0	35.0	6.02



6 ....Picture viewing




7 ....FAQ

Q1: Why choose our products:
1. We can provide you a wide range of oil seals.
2. Alibaba Assessed 8 year gold supplier.
3. Our oil seals has best quality and best service with competitive price.

Q2: How long is your delivery time?
A: Generally it takes 1-2 days if we have stock.

Q3: How to guarantee your after sales service?
1. Recheck the products before shipment to ensure our packaging in good condition
2. Track and receive feedback from our customer

Q4: Could you supply solutions to us?
A: Sure we can.

Q5: Do you have a minimum order requirement?
A: Small trial order is acceptable.

Q6: What are your payment terms ?
A: T/T, Western Union, .

Q7:To which places have you exported?
North America, Europe, Middle East, Africa, Southeast Asia and so on.

If you are looking for a company to help you building your own brand of seals , seal kits , o-ring kits , or any other OEM services for other products . You have found the right one . Our company provides professional OEM services on seals seal kits , o-ring kits and other products . For details ,
please contact us . We will reply you as soon as possible .
